Sand mill

2+

Public Playgrounds

Manual activity

Suitable for
children from 2 years old,
public playgrounds etc.,
social / manual activities

-

2.35 m

2.10 m

2.15 m

5.35 m

5.10 m

2.15 m

25.00 kg

340.00 kg

0.60 m

0.20 m, 0.40 m, 0.60 m

9 pieces - 0.40 x 0.40 x 0.40 m volume: 0.07 m3

-

-

-

-

-

2 pers.

2 h

Assembly time 2 fitters each 5 hours (without foundation creation)

Technical data
Floor area: 2.10 x 2.35 m
Minimum space: 5.10 x 5.35 m (22 m²)
Total height: 2.15 m
Platform heights: 0.20 / 0.40 / 0.60 m
Weight: 30 kg heaviest single part
330 kg in total

Support
post Support post made of Robinia plywood, milled cylindrically, Ø 120 mm. Unprotected end grain surfaces are covered with non-detachable post caps made of stainless steel.
Pipe stand made of stainless steel for the foundation and mounting of robinia round wood posts, Ø 120 mm, below the playing level.

Platform
floor Platform floor made of boards, 30 mm thick and all-round square timber beams 45 x 100 mm. The dried robinia lumber is planed, chamfered and free from rotten branches. Non-positive floor fastening thanks to special stainless steel brackets with a continuous bolt connection.

Attachment parts – Upright railing, anti-roll-off, made of stainless steel tube, Ø 33.7 x 2 mm
– Step railing made of stainless steel tube, Ø 33.7 x 2 mm
– Panel
balustrade made of highly weather-resistant HPL laminate board (yellow) – Pour wall made of HPL laminate board (yellow) with sand pouring pipe including butterfly valve, fastening between stainless steel pipes Ø 33.7 x 2 mm
–
mesh balustrade made of stainless steel pipe , Ø 33.7 x 2/25 x 2 mm, one-piece welded construction – sand elevator with transport container made of rubber and a 4 mm stainless steel chain, designed as a circumferential element, with it the transport container cannot be pulled into adjacent play areas or open spaces
– sand pouring pipe made of stainless steel

Metal components: stainless steel.
The robinia wood is provided with a water-repellent, breathable protective coating. In addition to protecting against moisture, this treatment reduces cracking. The modular add-on parts introduce their forces directly into the support posts via a special adapter attachment. The screw connections are secured against unauthorized loosening with cover caps.

Foundations (on site)
9 pcs. 0.40 x 0.40 x 0.40 m
Amount of concrete: 0.58 m³

Free fall height
0.60 m
