Ninja Frame Stendal

Ninja Frame Stendal

Ninja Frame Stendal is a durable and high-quality structure designed for outdoor use. It features a frame and posts that are constructed from stainless steel, ensuring longevity and resistance to corrosion. The wood used in this frame is Robinia, known for its strength and durability.

The Ninja Frame Stendal consists of various components, including a squared stainless steel frame. This frame is equipped with 6 x 3 climbing passages that are lined up and connected by frames. Each frame also has horizontal beams with planks made of Robinia, providing a sturdy and reliable surface for climbing. Additionally, there is a pair of handles attached to each frame, aligned inside for easy gripping.

The climbing passages of the Ninja Frame Stendal offer a wide range of activities. These include 2 x 4 rope ladders with stainless steel bars, aligned transversely, and 2 x 4 climbing ropes with rings made of stainless steel. There are also 2 x 3 swinging timbers, which are attached to climbing ropes and chains, providing a fun and challenging experience. Furthermore, there are 2 slacklines with 3 ropes made of Hercules rope, offering a unique and exciting element to the structure. Additionally, 2 x 4 stainless steel rings are attached to chains, providing additional climbing options. The structure also includes 2 x 3 rope ladders with stainless steel bars, longitudinally aligned, as well as 2 balance ropes and 2 x 5 climbing ropes with balance plates. Lastly, there are 2 x 4 balance plates attached to ropes and chains, adding a dynamic element to the climbing experience. The structure also features 2 triangular platforms, each with a height of 55 cm, positioned between 3 frames.

In addition to the climbing elements, the Ninja Frame Stendal also includes several climbing surfaces made of Robinia. These surfaces are positioned at different heights and are supported by stainless steel posts at the ends, ensuring stability and safety.

To enhance the durability and aesthetics of the structure, the frames and posts are powder coated. This coating not only adds a layer of protection but also gives the frame a sleek and modern look. The Ninja Frame Stendal is proudly made in Germany, ensuring the highest quality standards.

All support posts of the Ninja Frame Stendal are made of squared stainless steel tube measuring 120x120mm. To comply with environmental protection rules, all stainless steel surfaces are radiated with glass marbles. This process not only enhances the appearance but also adds an extra layer of protection against corrosion. The wooden parts of the structure are made of Robinia and are planed and chamfered for a smooth finish. It is important to note that all wooden parts are untreated.

The connection point between the net/rope and the support posts is achieved through a specifically formed stainless steel fork and a tensible stainless steel chain. This ensures a secure and reliable connection. The ropes and nets used in the Ninja Frame Stendal are made of Hercules rope, known for its strength and durability. All connecting parts of the structure are made of stainless steel or galvanized, ensuring long-lasting performance. Self-locking nuts are used for added security.

It is important to note that drying cracks may occur in all native hard woods, including Robinia. These cracks are considered normal and do not justify a warranty claim. This information is in accordance with the supplementary sheet to the German Institute for Standardization EN 1176, specifically Note 4.2.7.6.
