The frame and posts are constructed from stainless steel, while the wood used is Robinia.

– The frame is made of squared stainless steel.
– There are 21 climbing passages, which are lined up and connected by frames.
– Each frame has horizontal beams with planks made of Robinia.
– Inside each frame, there is a pair of handles attached.
– The climbing passages include:
– Two passages with three swinging timbers, attached to ropes and chains.
– Two passages with four climbing ropes featuring stainless steel rings.
– Two passages with four rope ladders, aligned transversely.
– Two passages with four balance blocks made of Robinia, attached to ropes and chains.
– A climbing rope with a balance plate between three frames.
– Three rope ladders with stainless steel bars, aligned lengthways.
– Four lion rings made of stainless steel, aligned transversely.
– A slackline with three ropes made of Hercules rope.
– A triangular platform, attached to chains between three frames.
– Two passages with four balance blocks made of Robinia, attached to ropes and chains.
– Two passages with five climbing ropes featuring balance plates.
– Three swinging timbers, attached to ropes and chains.
– A balance rope.
– Four climbing ropes with stainless steel rings.
– Four rope ladders, aligned transversely.
– There are several small climbing platforms made of Robinia, which are mounted on stainless steel posts at different heights.

The frames and posts made of stainless steel are coated with powder for added protection.

Made in Germany!
All support posts are made of squared stainless steel tube measuring 120x120mm.
All stainless steel surfaces are treated with glass marbles in accordance with environmental protection regulations.
All wooden parts are made of planed and chamfered Robinia. They are left untreated.
The connection point between the net/rope and support posts is achieved through a specifically formed stainless steel fork and a tensible stainless steel chain.
The ropes/nets are made of Hercules rope.
All connecting parts are made of stainless steel or galvanized, and only self-locking nuts are used.

Drying cracks are a normal occurrence in all native hard woods, even after proper storage and professional treatment. Therefore, drying cracks do not warrant a warranty claim. (Refer to the supplementary sheet for the German Institute for Standardization EN 1176, Note on 4.2.7.6)
