Mikado Construction “Gudensberg”

Mikado Construction – Gudensberg

Order Number: 1.0020-EM

– Octagon tower with eight radial inclined posts made of stainless steel, lacquered in a segmental Mikado design
– Octagon platform with an opening, measuring 250cm in height
– Spire roof made of HPL (optional standard color assortment) with a stainless steel cap
– Three pressure support posts made of stainless steel
– Net tunnel made of Hercules rope
– Safety barrier made of stainless steel
– Climbing wall with a step-through frame and climbing grips made of synthetic resin
– Ladder with stainless steel bars
– Spiel-Bau slide, box-shaped and made of stainless steel
– Horizontal net measuring 200x300cm with four horizontal ropes
– Two ropes between two posts
– Several balustrades and railings
– Rope labyrinth
– Hammock
– Small heap of logs

Made in Germany!

– All support posts are made of stainless steel tubes with a diameter of 101.6mm, lacquered in the Mikado design
– All wooden parts are made of Robinia, planed and chamfered. They are untreated.
– The visible ends of the posts are conclusively welded to a stainless steel cap.
– All stainless steel surfaces are radiated with glass marbles in accordance with environmental protection rules.
– The connection between the platform/railing and support posts is made through stainless steel press-in threaded sleeves.
– The platform is fixed using concentrically incorporated stainless steel brackets.
– The connection point between the net/rope and support posts is made through specifically formed stainless steel forks and tensible stainless steel chains.
– The nets are made of Hercules rope.
– All connecting parts are made of stainless steel or galvanized. Only self-locking nuts are used.

Please note that drying cracks are normal in all native hardwoods, even after appropriate storage and professional treatment. Therefore, drying cracks do not justify a warranty claim. (Refer to the supplementary sheet to the German Institute for Standardization EN 1176, Note on

Spiel-Bau GmbH
Alte Weinberge 21
14776 Brandenburg an der Havel
Phone: 03381 26140
Fax: 03381 261418

User Age6 - 14
Download Product Sheet

Technical Information


1829 x 1644 cm

Fall Height Group

250 cm



stainless steel, wood, HPL
