Cubic-Play Combination

Cubic-Play Combination

Cubic-Play Combination
Order Number: SK-160722-93
Made of stainless steel, the posts are constructed from stainless steel tubes with a diameter of ø101.6mm. The visible ends of the posts are securely welded to stainless steel caps. All stainless steel surfaces are treated with glass marbles in accordance with environmental protection regulations. The wooden components are made from Robinia, planed and chamfered, and remain untreated.

The set includes the following items:

– Yellow cube measuring 150x150x150cm
– Square platform with a height of 50cm
– Four wooden walls with various round and half-round openings, some of which have frames
– Horizontal wooden pent roof with a round opening
– Ladder with stainless steel bars
– Rope bridge with a length of approximately 300cm
– Green cube measuring 150x150x150cm
– Square platform with a height of 100cm
– Four wooden walls with star-like openings
– Spiel-Bau slide, box-shaped, made of stainless steel
– Net bridge with a length of approximately 300cm
– Blue cube measuring 150x150x150cm
– Square platform with a height of 50cm
– Four wooden walls with different triangular openings, some of which have frames
– Horizontal wooden pent roof with a triangular opening
– Wooden ramp with a climbing aid

All connections between the platforms, railings, and support posts are made using stainless steel press-in threaded sleeves. The platforms are securely fixed using concentrically incorporated stainless steel brackets. The connection points for the nets and ropes with the support posts are made using specially formed stainless steel forks and tensile stainless steel chains. The nets are made from Hercules rope, and all connecting parts are made from stainless steel or galvanized materials. Only self-locking nuts are used.

Please note that drying cracks are normal in all native hard woods, even after appropriate storage and professional treatment. Therefore, drying cracks do not warrant a claim under warranty (see supplementary sheet to the German Institute for Standardization EN 1176, Note on 4.2.7.6).
