Key Attributes

Age Group


Area of Use

Public Playground



Suitable for

Suitable for
all age groups,
public playgrounds etc.

Techincal Specifications

Lifting Device


Total Length

2.15 m

Total Width

1.90 m

Total Height

2.80 m

Minimum Space Length

5.20 m

Minimum Space Width

4.90 m

Minimum Space Height

2.80 m

Heaviest Single Piece

65.00 kg

(Total) Weight

310.00 kg

Free Height of Fall

0.55 m

Platform Heights

0.20 m


Foundation 1

6 pieces - 0.40 x 0.40 x 0.40 m volume: 0.07 m3

Foundation 2


Foundation 3


Foundation 4


Foundation 5


Foundation 6



Number of Installers

2 pers.

Assembly Time

3 h

Assembly Details

Assembly time 2 fitters each 3 hours (without foundation creation)

Technical Data

Technical data
Floor area: 1.90 x 2.15 m
Minimum space: 4.90 x 5.20 m (20 m²)
Total height: 2.80
Seat height: 0.35 m Platform height: 0.20 m
Weight: 65 kg heaviest individual part
310 kg in total

posts Support posts made of stainless steel tube Ø 120 mm covered with non-detachable post caps made of stainless steel.

floor Platform floor made of boards, 30 mm thick and all-round square timber beams 45 x 100 mm. The dried robinia lumber is planed, chamfered and free from rotten branches. Non-positive floor fastening thanks to special stainless steel brackets with a continuous bolt connection.

– railing made of stainless steel tube, Ø 33.7 x 2 mm, twist-proof
– tent roof, inclination 45 °, made of highly weather-resistant HPL laminate board, 13 mm. Fastening to the roof frame made of stainless steel tube Ø 33.7 x 2 mm
– Seat: made of colored, highly weather-resistant HPL laminate board, 20 mm

Metal components: stainless steel.
The robinia wood is provided with a water-repellent, breathable protective coating. In addition to protecting against moisture, this treatment reduces cracking. The modular add-on parts introduce their forces directly into the support posts via a special adapter attachment. The screw connections are secured against unauthorized loosening.

Foundations (on site)
6 pcs. 0.40 x 0.40 x 0.40 m
Amount of concrete: 0.38 m³
