Big Skyflyer

Key Attributes

Age Group


Area of Use

Public Playgrounds


Physical activity

Suitable for

Suitable for
children from 10 years,
public playgrounds etc.,
physical activity

Techincal Specifications

Lifting Device


Total Length

1.71 m

Total Width

1.71 m

Total Height

2.10 m

Minimum Space Length

7.71 m

Minimum Space Width

7.71 m

Minimum Space Height

2.10 m

Heaviest Single Piece

105.00 kg

(Total) Weight

180.00 kg

Free Height of Fall

0.45 m

Platform Heights



Foundation 1

1 piece - 1.40 x 1.40 x 0.70 m volume: 1.38 m3

Foundation 2


Foundation 3


Foundation 4


Foundation 5


Foundation 6



Number of Installers

2 pers.

Assembly Time

1 h

Assembly Details

Assembly time 2 fitters 1 hour each (without foundation creation)

Technical Data

Technical data
Base area: Ø 1.71 m
Minimum space: Ø 7.71 m (47 m²), of which fall area: Ø 5.71 m (25 m²)
Total height: 2.10 m
Weight: 105 kg, heaviest individual part
180 kg in total

– Post made of tubular steel, hot-dip galvanized, with base plate
– Hand wheel made of stainless steel, rotating
at an incline of 15 ° – Pivot bearing: multiple roller bearings in a dirt-protected, tamper-proof bearing housing made of stainless steel
– Anchoring takes place via a foundation ring that has to be concreted separately

Foundation (on site)
1 pc. 1.40 x 1.40 x 0.70 m
amount of concrete: 1.37 m³

Free fall height
0.45 m

Please note:
Under all playground equipment that causes forced movement of the user (e.g. swings, slides, seesaw devices, cable cars, carousels, etc.), shock-absorbing floors must be provided over the entire impact area.
