Play-Combination “Bürgerpark”
Order Number: 1.0031-201020-02-GA

This play combination includes the following features:

– Hexagon tower: This tower has a diameter of 180cm and a height of 250cm. It is equipped with six inclined posts made of stainless steel.
– HPL-climbing wall: An optional standard color assortment climbing wall with a step-through frame and climbing grips made of synthetic resin.
– Spiel-Bau slide: A box-shaped slide made of stainless steel with a height of 250cm.
– Climbing pole: A stainless steel pole for climbing.
– Parallel slide poles: Stainless steel poles for sliding.
– Jungle bridge: Made of Hercules rope with a central running rope made of PP. It has a length of 350cm.
– Stainless steel pressure posts: Four stainless steel posts for added stability.
– Square framework: This framework measures 90x90cm and has a height of 200cm. It is supported by four inclined posts made of stainless steel.
– Dangle arch: A structure with two posts made of stainless steel.
– Inclined climbing net: Made of Hercules rope.
– Handrails and balustrades: Several handrails and balustrades are included for safety.
– Rope labyrinth: A challenging rope maze.
– Stainless steel posts: Five additional stainless steel posts.
– Harp: Made of Hercules rope.
– Safety and climbing ropes: Multiple ropes made of Hercules rope for safety and climbing purposes.
– Wobbly bridge: A bridge with handrails on both sides, approximately 300cm in length.
– Square framework: This framework measures 90x90cm and has a height of 150cm. It is supported by four inclined posts made of stainless steel.
– Spiel-Bau slide: A box-shaped slide made of stainless steel with a height of 150cm.
– Rope ladder: Made of Hercules rope with stainless steel bars.
– Climbing ramp: A ramp with a rope made of Hercules rope.
– Inclines posts: Four inclined posts made of stainless steel.
– Triangle platform: A platform measuring 90x90x127cm with a height of 150cm.
– Chicken ladder: A ladder with a safety rope made of Hercules rope.
– Triangle platform: A platform measuring 90x90x127cm with a height of 110cm.
– Ladder: A ladder with stainless steel bars.
– Turnable crane: Approximately 220cm in height, with a stainless steel chain and rubber bucket.
– Sand chutes: One made of robinia and one made of stainless steel.
– Sieve table: A table for sifting sand.
– Handrails and balustrades: Several handrails and balustrades are included for safety.

Please note that this play combination does not include color design.

All support posts are made of stainless steel tube with a diameter of 101.6mm. The post heads are free and have flush welded stainless steel caps. The stainless steel surfaces are environmentally friendly glass bead blasted. The floor/railing connections are made through stainless steel-pressed-threaded sleeves, and the floor is mounted using stainless steel form angles set-in centered. The railing/support post connections are made through countersunk diagonal holes and stainless steel screws with special key head-theft protection. The net/rope points are connected to the support posts through specially shaped stainless steel forks and restretched stainless steel chains.

All wooden parts are made of Robinia, planed, and chamfered. They are left untreated. The nets are made of Hercules rope, and it is important to note that different color nuances may occur when using hemp-colored ropes. All connecting parts are made of stainless steel or galvanized, and all self-locking nuts are used.

Please be aware that drying cracks are normal in all local hard woods, even after appropriate storage and professional editing. Therefore, we cannot provide a warranty for drying cracks (see Addendum to DIN EN 1176, Note on 4.2.7.6).

This play combination is proudly made in Germany!

Download Product Sheet
