1.0051-EM

Mikado Construction “Beeskow”

Mikado Construction – Beeskow
Order Number: 1.0051-EM
Stainless Steel Posts
Wood: Robinia

– One hexagon stage with a diameter of 180cm and a height of 200cm, featuring six radially outwardly inclined posts. The posts are segmentally lacquered in a Mikado design.
– One HPL climbing wall (optional standard color assortment) with a step-through frame and climbing grips made of synthetic resin.
– One rope ladder made of Hercules rope with stainless steel bars.
– One Spiel-Bau slide made of stainless steel, box-shaped.
– One climbing pole made of stainless steel.
– One pair of sliding poles.
– One jungle bridge with a length of 300cm.
– Four pressure support posts made of stainless steel.
– One square platform measuring 90x90cm and with a height of 150cm. It features four radially outwardly inclined posts, segmentally lacquered in a Mikado design.
– One frame made of stainless steel for layaway, with two posts made of stainless steel.
– One inclined climbing net made of Hercules rope.
– One chicken ladder with one safety rope made of Hercules rope and one post made of stainless steel.
– Several balustrades and railings.

Made in Germany!
All support posts are made of stainless steel tubes with a diameter of 101.6mm, segmentally lacquered in the design of Mikado. The visible ends of the posts are conclusively welded to a stainless steel cap. All stainless steel surfaces are radiated with glass marbles in accordance with environmental protection rules.
All wooden parts are made of Robinia, planed and chamfered. All wooden parts are untreated.
The connection between the platform/railing and support posts is made through stainless steel press-in threaded sleeves. The platform is fixed using concentrically incorporated stainless steel brackets.
The connection point between the net/rope and support posts is made through specifically formed stainless steel forks and tensible stainless steel chains.
The nets are made of Hercules rope. All connecting parts are made of stainless steel or galvanized. Only self-locking nuts are used.

Drying cracks are normal in all native hardwoods, even after appropriate storage and professional treatment. Therefore, drying cracks do not justify a warranty claim. (Refer to the supplementary sheet to the German Institute for Standardization EN 1176, Note on 4.2.7.6)

Spiel-Bau GmbH
Alte Weinberge 21
14776 Brandenburg an der Havel
Phone: 03381 26140
Fax: 03381 261418

User Age5-14
Download Product Sheet

Technical Information

Fall Height Group

300 cm

Materials

Material

stainless steel, wood
